Situated in the vibrant industrial heart of Addis Ababa, Gugsa Flanges has established itself as a trusted name for precision-engineered components. We take pride in offering high-performance Titanium Grade 2 Flanges, a testament to our commitment to quality and durability. Recognizing the demanding requirements of modern industry, we ensure our flanges provide exceptional reliability for critical applications. Our role is to supply robust solutions that meet the rigorous standards of Ethiopia’s growing sectors, providing a dependable link for your most essential piping systems.
Titanium Grade 2 is commercially pure titanium valued for its excellent balance of strength and formability. Its composition is predominantly titanium, with trace amounts of iron and oxygen that contribute to its impressive mechanical properties. This grade offers outstanding corrosion resistance, particularly against chlorides and oxidizing environments, while maintaining a high strength-to-weight ratio. It is considerably lighter than stainless steel yet provides formidable durability and toughness, making it a highly efficient and long-lasting material choice for challenging conditions.
| Standards | GOST Flange, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092, BS, BS4504, BS 10, EN-1092, DIN, ANSI, ASME, DIN, MSS S44, ISO70051, ANSI/ASME B16.5, ASME/ANSI B16.5/16.36/16.47A/16.47B, B16.47 Series A & B, B16.48, EN |
|---|---|
| Pressure Rating ANSI | Class 1500, Class 150, Class 900, Class 2500, Class 300, Class 600, |
| Pressure Calculation in DIN | 10Bar, 16Bar, 25Bar, 40Bar, 6Bar, / PN16, PN64, PN40, PN25, PN10, PN6 |
| JIS | 16 K, 20 K, 5K, 10 K, 40 K, 63 K, 30 K, |
| UNI | 10Bar 16Bar 6Bar 25Bar 40Bar |
| EN | 6Bar 25Bar 40Bar 10Bar 16Bar |
| Most common Types | Threaded / Screwed / Forged / Plate |
| Production technique |
|
| Shapes and Types we produce | Large Male-Female (LMF), Ring Type Joint (RTJ), Flat Face (FF), Small Tongue, Small Male-Female (SMF),Raised Face (RF), Large Tongue & Groove, Groove, Lap-Joint Face (LJF) |
| Test | Direct-reading Spectrograph, Magnetic particle detector, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector |
| Equipment | Pushing Machine, Press machine, Bending machine, Sand-blasting machine, electric bevelling machine etc |
Gugsa Flanges, a leading supplier in Addis Ababa, Ethiopia, offers an extensive selection of Titanium Gr 2 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Titanium Gr 2 Flanges find extensive use in industries that demand superior corrosion resistance and a strong strength-to-weight ratio. You’ll commonly see them in **chemical processing plants, marine environments, desalination systems, heat exchangers, and aerospace components**. They are also well-suited for **oil and gas refineries**, **power generation**, and **pharmaceutical equipment**, where both purity and durability are essential. Their resistance to chlorides, acids, and seawater makes them ideal for offshore and coastal applications. With Titanium Grade 2 Flanges, you can expect a long service life, lower maintenance costs, and excellent compatibility with harsh and corrosive operating conditions.
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
Yes, we offer custom sizes for Titanium Gr 2 Flanges to meet specific project needs. Our team at Gugsa Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@gugsaflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
